IOtech Driver Software

Encore
Encore is the premier Out-of-the-Box data acquisition software package and is included with each 6000 Series module. Encore combines ease of use with advanced functionality, including customisable data layouts, powerful analysis, and reporting capabilities. Instead of having a program to log data, another to analyse, and a third to develop report data, Encore includes the functionality of all three into one package, thus shortening the learning curve and saving time and cost.

• Interactive measurement software for Out-of-the-Box setup, acquisition, display, logging, analysis and reporting
• Advanced feature set with no programming required
• Drag-and-drop functionality
• Easy-to-use set-up wizards
• Ability to drag data directly to Excel®
• Included data analysis tools
• Playback mode
• Sophisticated test report capability
• Incorporate multiple 6000 Series devices into one application
• Supported Windows® Operating Systems: Windows 7 (32-bit or 64-bit),
• Windows Vista (32-bit or 64-bit), Windows XP SP2 (32-bit), Windows 2000 SP4

DAQView
DaqView allows you to verify signal connections, acquire and save data to disk, and graphically view real-time data within moments of taking your IOtech hardware Out-of-the-Box. Easily set up all of your hardware, acquisition, and display parameters without programming via a simple spreadsheet-style screen. DaqView is a full-featured acquisition and display application that provides all the functionality you’ll need for most data-logging applications.

• Included with all IOtech DAQ Series and Personal Daq/3000 Series products
• Spreadsheet-style channel configuration and set-up
• Real-time displays include Digital, Dial, Bar Graph, Strip Chart and Scope
• Real-time storage to disk
• Scaling and averaging functions built-in
• Setpoint output configuration mode
• Export directly to Excel® and MATLAB®, plus a wide variety of output formats including Text, DIAdem®, DASYLab®, .wav, UFFA and UFFB
• Overlay recorded with real-time data
• Frequency analysis and display
• Supported Windows® Operating Systems: Windows 7/Vista/XP SP2, 32-bit or 64-bit

Supported Hardware:
DaqBoard Series – Cost-Effective PCI Plug-In Boards for Data Acquisition
DaqBoard/3000USB Series – USB High-Speed OEM DaqBoards
DaqBook/2000 Series – Ethernet-Based Systems for Various Sensor Types
DaqLab/2000 Series – Ethernet-Based Bench-Top Systems
DaqScan/2000 Series – Ethernet-Based Rack Mount Systems
DaqOEM Series – Board-Level Ethernet-Based Data Acquisition for OEM
DaqTemp – PCI Thermocouple Multifunction Data Acquisition Board
Personal Daq/3000 Series – USB 1 MHz, 16-Bit Multifunction DAQ Modules

PersonalDAQView
Personal DaqView, IOtech’s included Out-of-the-Box graphical data acquisition software, is an easy-to-use yet powerful application. It allows users to configure a test, and display or record data within minutes, without programming.

• Set up Analogue Input Channels for acquiring various voltages or temperature
• Set up Frequency/Pulse Input Channels to measure various frequency-related parameters, e.g., pulse rate, total pulses, pulses per scan, percentage high, percentage low
• Set up Digital I/O Channels for input or output
• Save acquired data to disk
• Transfer data to spreadsheets, data bases, and PostView
• View real-time data values in screen columns, scrolling charts, bar graph, analogue, or digital metres
• Support for up to 100 Personal Daq devices attached to one PC
• Chart Setup Wizard feature you can make use of Simple, Moderate or Advanced automatic chart creation functions
• Includes add-ins to Microsoft Excel™ and can be run from within the Excel environment, using Excel’s associated macros
• Supported Windows® Operating Systems: Windows 7/Vista/XP SP2, 32-bit

Supported Hardware:
Personal Daq/50 Series – USB High-Resolution Data Acquisition Modules

WaveView
WaveView is a Windows-based setup and acquisition application that allows you to configure, display, and save data to disk within minutes of taking the WaveBook Out-of-the-Box. WaveView provides a point-and-click interface that simplifies operation of the WaveBook by allowing setup of all hardware, including the field-installable WBK options, without programming or connecting icons.

• Set up all analogue or digital input parameters
• Acquire and save data to disk
• View the acquisition in real-time
• Send data to other Windows® applications, such as spreadsheets and databases
• Launch an independent post-data acquisition application to review file data recorded by WaveView
• Supported Windows® Operating Systems: Windows 7/Vista/XP SP2, 32-bit or 64-bit

Supported Hardware:
Strainbook/616 – Ethernet-Based Strain Gage Measurement System
WaveBook/516E – Ethernet-Based Portable High-Speed Waveform DAQ

PostView
PostView is a time and frequency domain post-acquisition data viewing package which is integrated and ready to use from within your View package when you install it. PostView provides easy to use basic time and frequency domain data viewing for IOtech data acquisition View packages including DaqView, WaveView, Personal DaqView, LogView and ChartView.

• Up to 8 time domain function windows which can be tiled by the user for easy display customisation
• Up to 16 channel traces can be displayed in each time domain function window
• Single and dual cursors to easily interpret individual data points
• Window, trace, and cursor colors can be customised for user preference
• Displayed data is automatically scaled to optimally fit function window
• Frequency domain analysis and display
• Supported Windows® Operating Systems: Windows 7/Vista/XP SP2, 32-bit or 64-bit

– Can be integrated with other IOtech software such as DaqView, PersonalDaqView, WaveVIew, LogView and ChartView.

DaqCOM
DaqCOM is a family of powerful programming tools for IOtech’s WaveBook and Daq products. DaqCOM uses Microsoft®’s Component Object Model (COM) to provide a host of features for users who are developing custom applications with IOtech data acquisition products. DaqCOM can be used with any COM-compatible language, including Visual Basic®, C++®, and C#®. DaqCOM support for Windows ® .NET** is accomplished by utilising the COM interoperability layer included with Visual Studio® .NET.

• Save/Load feature allows acquisition configurations to be saved and loaded by the same or other applications
• Synchronise multiple devices from one application
• Data formatting options include raw binary, engineering units and mx+b scaling on a per channel basis
• Programming templates allow you to quickly develop your application from IOtech-generated templates
• Obtain HTML-style, context-sensitive help on any property or method quickly and easily
• View documentation on-line from the Visual Studio environment for easy access
• Supported Windows® Operating Systems: Windows 7/Vista/XP SP2, 32-bit or 64-bit

What do our Customers say about us?

Here is to the best software support team – ever! Many, many thanks. You have definitely made my day! yay!! 🙂

You have set a benchmark standard that many other companies should aspire to.

I would like to sincerely thank you for your extremely prompt and efficient service – much appreciated and rare these days.

Just would like to express my sincere appreciation to both Adept Scientific UK and Vissim Support team on their swift efficient and friendly responses of my problems. This is by far the best customer services I have received. Thank you.

Iotech Daq 3000 Driver

For the time being we are unable to offer the following product ranges although we are currently working hard to increase the number of products we can offer in the future. Please contact us to talk about alternative products that we may be able to offer you.

Machine Vibration Monitoring Software for the ZonicBook™ and WaveBook™.

eZ-TOMAS is the economical solution to rotating machinery monitoring and analysis. eZ-TOMAS will monitor your machines on a 24 hour basis. Data is continuously acquired and limit checked. eZ-TOMAS retains the change in vibration condition and quickly provides you with the information you need to make critical decisions. eZ-TOMAS can be quickly setup to measure rotating machinery vibration data. Machine configuration and acquisition information can be copied from templates or copied from existing projects. Accessing rotating machinery displays are as simple as double-clicking on the desired input channel. eZ-TOMAS checks vibration data at both alert and alarm levels. Alarm levels can either be set by you; or eZ-TOMAS can automatically calculate alarm levels based on past machine operation. Changes in vibration levels indicate changes in a machine’s operating condition, which are warning signs of potential machine failure.
