View and Download MobileDemand XTablet T1600 user manual online. XTablet T1600 tablet pdf manual download. Apart from this, it entails the comprehensiveassessment of a number of factors like constraints, opportunities, drivers, challenges,and risk. Further, it the global Fully Rugged Tablets market is bifurcated on the basis of diverse parameters into respective segments as well as sub-segments. Choose the solution that works for you. MobileDemand proudly offers our diverse lineup of rugged tablets and cases, engineered tough to withstand the most rugged work environments.
Download Spec Sheet
Physical and environmental characteristics
| Dimensions: | 9.16' W x 5.91' H x 0.87' D (232.6 mm W x 150 mm H x 22 mm D) |
| Display: | 8' diagonal widescreen |
| Weight: | 1.87 lb. (0.85 kg) - base configuration |
| Sealing: | IP 65 (water and dust) |
| Drop / Shock: | 26 repeated drops to 1 operating unit on to plywood over concrete from 60 inches |
| Operating Temp: | 14° F to +122° F (-10° C to +50° C) |
| Storage Temp: | -4° F to +140° F (-20° C to +60° C) |
| Humidity: | 95% non-condensing |
Performance characteristics
| Processor: | Intel® Atom X5-Z8550 |
| System Memory: | 8GB RAM LPDDR3 |
| Storage Drive: | 128GB eMMC |
| Operating System: | Windows® 10 Professional |
| Display: | 1280 (W) x 800 (H) IPS; 370 nits 10-point project capacitative touch, rain drops and thin gloves Stylus included |
| Buttons: | Barcode scanner trigger, power, volume +/- |
| I/O Board Configuration: | Micro HDMI, USB Type A 3.0 (2), audio, power jack |
| Battery System: | XL High Capacity: 43Wh, 11850mAH (Up to 15 hours)1 Hot swappable with 150mAH backup battery |
| Audio: | Intel® HD audio, built-in microphone |
| Barcode Scanner: | High performance N6703 2D barcode scanner (optional) |
| Camera: | 8MP integrated w/ LED flash (rear-facing) and 2MP integrated (front-facing) Optional rear-facing 3D camera (Intel RealSense R200) |
Wireless & GPS network characteristics
| Wireless | Intel Wireless-AC 9260 (2.4/5.0 Ghz) (a/b/g/n/AC) |
| Bluetooth: | 5.1 |
| GPS: | Included: Ublox NEO-M8N |
| WWAN: | 4G/LTE available - Contact Sales@MobileDemand.com for supporting cellular carriers |
.jpg?v=635869280235694899 "Drivers mobiledemand xerox")
Regulatory approvals
| xTablet T8650: | FCC Class B , FCC/SAR, cUS, CE, CB, TUV, |
| 1Battery life varies significantly depending on settings, app usage, and other factors |
Large Screen, Lightweight Device for Enterprise Operations. A Rugged Workhorse.
Drivers Mobiledemand Test
- The xTablet T1680 has a high performance Intel® Core™ i5 processor (quad-core) with 8GB of DDR4 RAM.
- Comes with Microsoft® Windows® 10 with a 256GB hard drive. Optional 512GB available. Contact us for more information.
- Verizon LTE certified (also works with other carriers.)
- A large 11.6' 1920x1080 display with sunlight viewable option with light-filtering technology and high contrast ratio for increased clarity and a wider viewing angle eliminating reflection, utlimately making it easier to view in direct sunlight.
- IP65 sealed against water and dust.
- Choose an optional 2D barcode scanner to turn your ruggedized tablet into the field productivity tool for which you've been waiting.
- The high-power, up to 7-hour1 battery means added time in the field without having to plug in the device to charge.
- Bluetooth 5.0 and built-in GPS (optional) means greater functionality and increased productivity for field employees.
- Interested in a C1D2 certified rugged tablet for hazardous environments? Click here
